CATALOGUE - Wheel Trims
The purpose of this document is to show the wheel trims catalogue.
Overview#
Purpose: The purpose of this document is to show the wheel trims catalogue.
Scope: Applies to all assigned Bragan personnel.
Responsibility: It is the responsibility of each employee to ensure the process set out in this procedure is followed.
Objective: The objective of this document is to guide Bragan employees on different wheel trims items.
ITEM TITLE BARCODE SUPPLIER SKU CODE IMAGE REMARKS
| 22.5'' Universal Front Outer - (CHD) | 5251 |
|---|---|
| 22.5'' Universal Front Outer - Doughnut - (CHD) | 5252 |
| 17.5'' Universal Front Outer Single - Closed 6 Stud - (CHD) | 5751 |
| 19.5'' Universal Front Outer - Single - 8 Stud - (CHD) | 5951 |
| 19.5'' Universal Front Outer - Doughnut - (CHD) | 5952 |
|---|---|
| 17.5'' Swedish Style Front Wheel Trim Covers - Single - (CHD) | 10175F |
| 17.5'' Swedish Style Rear Wheel Trim Covers - Single - (CHD) | 10175R |
| 19.5'' Universal Truck Front Wheel Sleeves Trims - Single - (CHD) - 61019F | 10195F |
| 19.5'' Universal Truck Rear Wheel Sleeves Trim - Single - (CHD) | 10195R |
| 22.5'' Universal Truck Front Wheel Sleeves Trims - Swedish - (CHD) | 61022F |
| 22.5'' Universal Truck Rear Wheel Sleeves Trims - Swedish - (CHD) | 10225R |
|---|---|
| 17.5'' Universal Front Bus Coach Truck S/S Wheel Trims - Single - (CHD) - 62017F | 20175F |
| 17.5'' Universal Rears Bus Coach Truck S/S Wheel Trims - Single - (CHD) - 62017R | 20175R |
| 22.5'' Universal Rear Wheel Sleeves - 295/80 - 280mm - Single - (CHD) | 22513R- 280MM |
| 22.5'' Universal Rear Wheel Sleeves - 315/80 - 300mm - Single - (CHD) | 22513R- 300MM |
| 19.5'' Universal Front Inner Wheel Sleeve - (CHD) | 70195F |
| 19.5'' Universal Rear Wheel Sleeves - 280mm - (CHD) | 70195RS-6 |
|---|---|
| 19.5'' Universal Rear Wheel Sleeves - 265mm - (CHD) | 70195RZ-6 |
| 22.5'' Universal Front Inner Wheel Sleeves - (CHD) | 72204F-A |
| 22.5'' Universal Rear Wheel Sleeves 295/80 - 280mm Deep - Single - (CHD) | 72204R- 280MM |
| 22.5'' Universal Rear Wheel Sleeves - 285mm Deep - Single - (CHD) | 72204R- 285MM |
| 22.5'' Universal Rear Wheel Sleeves 315/80 - 300mm Deep - Single - (CHD) | 72204R- 300MM |
|---|---|
| 22.5'' Universal Front Wheel Trim Covers - (CHD) | 72207F |
| 22.5'' Universal Rear Wheel Trim Covers - (CHD) | 72207R |
| Trailer Wheel Trim Covers Sleeves - Single - (CHD) | 73225S-6 |
| 22.5'' Inner Cones x 2 - (CHD) | 250RP + 250RH |
| 16'' Ford Transit Front Wheel Trim Covers - (CHL) | 71605F |
| 16'' Universal Front & Rear Wheel Trim Covers - Transit etc - (CHL) | 71605FR |
|---|---|
| 16'' Ford Transit Rear Wheel Trim Covers - (CHL) | BRA16003R |
| 2x Universal Super Singles Wheel Trims Covers Set - 120mm - (CHL) | 71225S- 120A |
| 2x Universal Super Singles Wheel Trims Covers Set - 130mm - (CHL) | 71225S- 130A |
| 2x Universal Super Singles Wheel Trims Covers Set - 135mm - (CHL) | 71225S- 135A |
| Isuzu NPR Wheel Trim Covers / Sleeves Front and Rear - 17.5'' - (CHL) | 71701F/R |
| 2006 - 2014 Iveco Daily 16'' Wheel trim Covers Dual Rear Wheel - Heavy - (CHL) | 53016 |
|---|---|
| 2006 - 2014 Iveco Daily 16'' Wheel trim Covers Dual Rear Wheel - Standard - (CHL) | 52016 |
| 2014+ Ford Transit MK8 16'' Wheel Trim Covers Deep Rear - Dual Rear Wheel - (CHL) | 71617 |
| 16'' Sprinter / Crafter Wheel trim Covers - Dual Rear Wheel - (CHL) | 70016 |
| 19.5'' Universal Super Singles Wheel Trims Covers Set - 120mm Offset x2 - (CHL) | 71195S-6 |
| 19.5'' Universal Super Singles Wheel Trims Covers - 0mm Offset - x2 - (CHL) | 73195S-6 |
|---|---|
| 32mm nut cover - Single Parent (DONT LIST) - (CHD) | 32MM |
| 33mm nut cover - Single Parent (DONT LIST) - (CHD) | 33MM |
