Grill Bar Brackets
To show a list of Truck Grill Bar Brackets.
Overview#
Purpose: To show a list of Truck Grill Bar Brackets.
Scope: Applies to all assigned Bragan personnel.
Responsibility: It is the responsibility of each employee to ensure the process set out in this procedure is followed.
Objective: To guide all Bragan employees about Truck Grill Bar Brackets.
| Grill Bar Brackets | |
|---|---|
| Volvo FH2 and FH3 Pre 2013 BRA2552B | |
| Volvo FH4 + FM 4 2013+ BRA22602 | |
| Volvo FE and Renault Premium Bar B,C + D BRA22722 |
| Scania R Series 2004 - 2009 BRA21102 | |
|---|---|
| Scania 6 Series 2009+ (same as above but with added flat plate) Flat plate - 21502 + 21102 | |
| Renault T Cab / Volvo FH2 and 3+ FM2 and 3 when using pointed spacer (Towing eye left free) | |
| Volvo Grill Bar A - factory bracket | FH4 Brackets |
| DAF CF (same as XF 105 but longer) BRA2312 |
Notes#
This section is important so Adhoc points and issues can be logged. Also, Q&A can be logged for suggestions for potential issues encountered. Also, log important notes needed for this system. Additional Notes:
The table above is a sample of Grill Bar Brackets. To show a list of Truck Grill Bar Brackets. *Purposed, Scope, Responsibility, and Objective were added by the uploader temporarily. May still need some updates/revision by the owner.
Potential Issues:
1 - ISSUE ENCOUNTERED: Stuck on Loading
RESOLUTION: Refresh Browser
2 - ISSUE ENCOUNTERED: Broken Links
RESOLUTION: Get the external link as this will allow other people to access the SOP without the need for login credentials and avoid broken links.
3 - ISSUE ENCOUNTERED: "Type Text Here"
RESOLUTION: "Type Text Here"
Attachments#
Grill_Bar_Brackets.xlsx 16/12/2025
